Purpose of the course (Installation Design 1 – early classes)

The course focuses on electrical installations in low-complexity buildings, especially residential electrical energy provision. It aims to help learners understand:

  • Core concepts of electricity
  • The electrical components used in such installations
  • Criteria for where components should be located
  • How to execute/layout energy distribution conduits through a house
  • How to calculate components (implied by course objectives)

Why electrical installations matter

Electricity is indispensable in daily life, providing:

  • Comfort
  • Time-saving
  • Entertainment
  • Tools for work and daily activities (e.g., TVs, sound systems, computers)

Installations must be designed to be:

  • Efficient
  • Comfortable
  • Economical
  • Safe for people, property, and buildings

Failures can cause electrocution and fires, so safety is a central concern.

Concepts explained (electricity basics)

Atomic structure and charge

Matter is made of atoms containing:

  • A nucleus with:
    • Protons (positive charge)
    • Neutrons (neutral)
  • Electrons (negative charge) orbiting the nucleus

Normally, materials are neutral (electrons and protons balance). If electrons move between materials, charged bodies form.

Charge behavior

  • Same charges repel
  • Opposite charges attract
  • Electric charge is a property that produces attraction/repulsion forces.

Electric current and circuits

  • Electric current is the ordered movement of free charges (usually electrons) through a conductor.
  • An electric circuit is a closed path that transfers energy from:
    • a generator (source/producer),
    • through a conductive medium,
    • to a receiver (consumer).

Key electrical quantities

  • Potential difference (voltage): difference in charge between two points, measured in volts (V)
  • Current intensity: charge passing through a conductor per second, measured in amperes (A)
  • Power: energy consumed per unit time, measured in watts (W)
    • More watts → consumes more energy per unit time

Note: The subtitles also mention “torque” as a maximum energy a device can reach for sizing; this appears somewhat imprecise in the context shown.

Circuit types

Series circuits

  • Devices connected end-to-end
  • Components operate together (turn on/off simultaneously)
  • Resistance effectively increases as more devices are added, so current behavior changes as described
  • If one component fails/opens, the circuit opens and others stop working

Parallel circuits

  • Inputs are tied together
  • Devices can be switched independently
  • As described, resistance does not increase in the same way; each branch keeps its own current conditions
  • If one device fails/disconnects, others keep working

How electricity reaches homes (system overview)

From generating station to user

Electricity moves through a chain of voltage transformations and distribution stages:

  1. Generating station → high-voltage transmission
  2. Transformer stations
    • reduce voltage from 132 kV to 13.2 kV
  3. Transformer substations
    • reduce from 13.2 kV to 380 V or 220 V
  4. City distribution network
    • described as a ring pattern around blocks to reach users

System boundary components

The main elements that connect the external network to the house include:

  • Electrical connection: links external distribution network to the house’s internal installation
  • Meter: measures energy usage
  • Main panel: organizes the installation and contains protection/control devices
  • Protective devices: protect the installation (and people, as described)
  • Pipes and conductors: carry energy to points of use
  • Boxes: house terminals/fixtures/switches/junctions, etc.

Electrical connection and distribution network (low-complexity building framing)

House distribution network conductors

The house line is described as a four-wire line:

  • Phases: R, S, P
  • Negative conductor: O (neutral/return described by letter)

Voltage obtained by connection type

  • Single-phase
    • one live wire + neutral
    • 220 V (most common domestic use)
  • Three-phase
    • three live wires + neutrals
    • 380 V (for higher consumption; higher electromotive force)

Installation layout: overhead vs underground distribution

Overhead distribution

  • Conductors descend to insulators
  • Enter the crossarm
  • Go via a service line to the meter
  • Meter placed on a service pole or wall

Underground distribution

  • Cables laid under sidewalks using conduits
  • Branch line installed at approximately 70 cm below sidewalk level
  • Uses watertight boxes along the route; from these, the line runs to the house

Connection options described

  • Overhead via pillars when the house is not on the property line
  • Underground approach using boxes along the connection route

Meter (function and placement)

Meter operation

  • Records consumption using a rotating disc
  • Disc speed corresponds to consumption
  • Revolutions are accumulated by a mechanism
  • Reading method:
    • take current reading and compare with previous reading to determine consumption for the period
  • Energy is recorded in kilowatt-hours (kWh)

Meter location rules (as described)

  • Must be placed on the property line
  • If the facade is set back, place on a pillar at that line
  • Meter box reference height (as stated):
    • 15–17 m from meter window to finished floor level

Examples of placement

  • Meter on a service wall
  • When set back, possible pillar types:
    • precast concrete pillars
    • cast-in-place concrete pillars
    • masonry pillars capable of holding:
      • only the electric meter, or
      • electric + gas meters

Main panel (function and interior components)

Role

  • Contains protection/control elements
  • Organizes interior circuits

Placement

  • Must be in an easily accessible location for operating devices

Feed and outgoing circuits

  • Line enters from the meter into the main panel
  • Inside includes protection elements such as:
    • Circuit breaker
    • Thermal-magnetic breaker
    • Residual Current Device (RCD)
    • Thermal switches for each circuit
  • Power lines then go out to the house circuits

Construction

  • Generally sheet metal (size depends on the number of elements)
  • Often recessed into the wall
  • May include secondary/sectional panels for multi-story buildings or different areas

Protective devices (what they protect against and how)

Thermal-magnetic circuit breaker (main panel)

Protects against:

  • Short circuits
    • sudden/high current rise due to a fault (e.g., opposite conductors touching)
  • Overloads
    • current greater than normal causing conductors to heat up

Mechanism described as two trip functions:

  • Magnetic trip
    • reacts to violent current rise
    • increases magnetic field
    • attracts the core and opens the circuit
  • Thermal trip
    • heat deforms a metal element and opens the circuit

After a trip, a coupled switching element restores operation.

Residual Current Device (RCD)

Protects people by preventing dangerous leakage currents to ground.

Accident types described:

  • Direct contact: person touches a live part
  • Indirect contact: person touches an energized conductive part due to insulation failure (e.g., motor/washing machine casing)

Operation described:

  • monitors incoming vs outgoing current
  • interrupts when it detects a difference (leakage) for a short time

Stated operating criteria (as given):

  • Leakage current threshold: ≤ 30,000 amps
  • Interruption time: < 30 milliseconds

Grounding (for indirect contact protection)

Purpose:

  • divert fault current to earth through a lower-resistance path than the human body

Common type described:

  • Ground rod
    • iron pipe in a borehole
    • buried about 2 meters
    • connected to a cable running through the installation

Conductors and conduits (types and intended uses)

Conductors

Common types

  • Typically electrolytic copper, described as filamentary elements
  • Single insulated conductors
    • most common in building installations
    • multiple insulated wires under thermoplastic or PVC coating

Underground cables

  • Copper or aluminum conductors
  • Each conductor has PVC insulation
  • Assembly wrapped with synthetic material and an outer sheath
  • Flame non-propagating and usable in water/corrosive environments
  • Suitable where mechanical damage risk exists

Outdoor cables

  • Resistant to solar radiation/weathering
  • Aluminum alloy wires with insulation of cross-linked polyethylene

Conduits

Purpose

  • Housing for conductors
  • Made of steel or plastic

Steel conduits

  • Manufactured in ~3 m sections (rigid or flexible)
  • Commonly rigid; connected with screw connectors
  • Grades:
    • heavy-duty (less common; more industrial)
    • medium-duty (for high-cost projects with special characteristics)
    • lightweight (most common in homes)

Plastic conduits

  • Rigid or flexible; often also in ~3 m rigid lengths
  • Rigid PVC
    • expanded end for joining with glue
    • easy to bend/cut, doesn’t corrode, doesn’t propagate flames
    • not suitable for outdoor use
  • Flexible PVC
    • manufactured in 50 m rolls
    • economical, but usage is restricted

Plan representation

  • Pipe diameter varies with number of conductors and drawing conventions:
    • red dashed = new construction
    • black dashed = existing construction
  • Buried pipes have specific representation as well.

Conduit installation modes

  • Embedded in walls
    • cut wall to place pipe; cover with plaster afterward
  • Aerial (attached) conduits
    • metal fixed with large bolts to rigid wall parts
    • PVC aerial variant allowed only indoors
  • Buried conduits
    • require mechanical protection (brick or precast concrete elements)
  • Conduits in slabs/ceilings
    • slab: lay before concrete fill
    • ceiling: install boxes and conduits before closing with plasterboard or applied plaster

Boxes and outlets (where energy is used)

Boxes

  • Installed at points where energy is used
  • Conduits and conductors arrive; connections are made inside:
    • conductor-to-conductor, or conductor-to-device

Outlets and device boxes

  • Boxes where devices (light fixtures or receptacles) connect are described as outlets/connection boxes
  • Boxes for switching elements (e.g., light switches) and branching/junction boxes:
    • specifically stated as not considered outlets in the described terminology

Box types (as described)

  • Octagonal boxes
    • commonly for light fixtures on ceiling or wall
  • Rectangular boxes
    • for switches, outlets, TV/telephone outlets
  • Square boxes
    • generally used for junction/distribution of some outlets
  • Small boxes
    • for doorbell buttons/chimes

Symbols and color conventions

  • Red vs black
    • red = new construction
    • black = existing construction
  • Low-voltage elements (as stated):
    • green: doorbell button and chime
    • blue: telephone connections
    • brown: television connections
