Capacitor: General Specifications of the Capacitor Explained

Main summary

Key takeaways

Technology

Overview

The video explains key datasheet specifications and how they determine which capacitor type is suitable for a given electronic application (e.g., timing/wave shaping, decoupling, and filtering). It emphasizes that capacitor “real” behavior depends on test conditions and the operating environment.

Main capacitor specifications covered

Rated / nominal capacitance (C)

  • The capacitance value the capacitor is designed for, shown on the capacitor and in the datasheet.
  • Measured in farads; commercially it can range from picofarads up to hundreds of farads.
  • Actual capacitance varies with:
    • Temperature
    • Frequency
    • Operating voltage
    • Age
  • Datasheets specify test conditions (example given: an electrolytic capacitor rated 1 µF at 120 Hz and 0.25 V).

Tolerance

  • The allowed deviation from the rated capacitance, expressed as a percentage (%).
  • Varies by capacitor type (about 1% to 20% mentioned).
  • Example: 20% tolerance means actual capacitance could be ±20% (e.g., 1 µF could be ~0.8–1.2 µF).
  • Important when applications require tight capacitance accuracy.

Temperature range

  • The operating temperature range over which the capacitor functions properly.
  • Mentioned range: -55°C to 125°C (depends on type).

Temperature coefficient

  • How capacitance changes with temperature, typically expressed as:
    • % over the full range, or sometimes
    • ppm/°C
  • Example: ±1% means capacitance varies by ±1% across the operating temperature span.
  • Also notes capacitance may depend on frequency and bias voltage.

Bias / frequency dependence (noted for ceramic, especially Class 2)

  • For some capacitors—especially ceramic Class 2—capacitance can change significantly with applied bias voltage.
  • This must be considered during selection.

Rated / nominal voltage

  • The maximum DC (or peak pulse) voltage the capacitor can continuously withstand.
  • Varies widely (about 10 V to 10 kV mentioned).
  • Exceeding rated voltage can damage the capacitor, so the selection must ensure operating voltage stays below the rating.

Volumetric efficiency (size/space-oriented metric)

  • Defined as capacitance per unit volume.
  • Depends on the dielectric medium and dielectric thickness.
  • Expressed as a C·V product per unit volume (where C = capacitance and V = rated voltage).
  • Manufacturing improvements have improved volumetric efficiency over time.

Leakage current / insulation resistance

  • The dielectric is not a perfect insulator, so leakage current flows.
  • Leakage causes a voltage drop over time; datasheets specify the measurement time because leakage decreases and stabilizes after some period.
  • Leakage current is commonly in the nA to µA range.
  • For film/ceramic capacitors, leakage is often specified as insulation resistance (typically in gigaohms), defined as:

insulation resistance = applied capacitor voltage / leakage current

Equivalent Series Resistance (ESR) and Equivalent Series Inductance (ESL)

ESR (series resistance)

  • Capacitors behave non-ideally due to internal components:
    • ESR models AC losses (series resistance).
    • Parallel resistance corresponds to insulation/leakage behavior.
  • Why ESR matters:
    • High AC currents cause power dissipation:
      • P = I²·ESR
    • This generates heat and increases temperature.
    • Reliability depends on keeping capacitor temperature within rated limits.
  • Manufacturers may provide dissipation factor instead of ESR:
    • Dissipation factor relates ESR to the capacitor’s reactance at the test frequency.
  • Goal: keep ESR / dissipation factor low to minimize heating.

ESL (series inductance)

  • ESL is negligible at low frequency but becomes important at high frequencies.
  • ESL causes a series resonant frequency:
    • Below resonance: capacitor behaves mainly capacitive
    • Above resonance: behaves more inductively
    • At resonance: impedance magnitude in the model is related to ESR
  • For high-frequency applications, select capacitors with low ESL.

Conclusion / takeaway

Different capacitor types are chosen based on which datasheet specifications best match the application’s requirements—such as accuracy, voltage stress, temperature behavior, leakage, and AC/high-frequency performance.

The presenter previews that a next video will cover different capacitor types and their usage.

Main speaker/source

  • Speaker: The presenter from the YouTube channel “ALL ABOUT ELECTRONICS”.
