Main Ideas / Lessons from the Class (Networking → Data Link Layer & Flow Control)

1) Data Link Layer basics (OSI model)

  • The Data Link Layer is the 2nd layer of the OSI model.
  • Key jobs discussed:
    • Frame creation
    • Flow control: controlling the rate/speed of data transmission between sender and receiver

2) Flow Control concept

Flow control is a mechanism that:

  • Controls the speed of data transmission between sender and receiver
  • Prevents a fast sender from overwhelming a slower receiver
  • Avoids issues like buffer overflow and data loss
  • Achieves speed matching primarily through feedback from the receiver (e.g., acknowledgements)

Flow Control Techniques (Detailed Points)

A) Stop-and-Wait Flow Control / Stop-and-Wait ARQ

Core rule

  • The sender transmits exactly one frame.
  • Then it waits for ACK before sending the next frame.

Acknowledgement (ACK) meaning

  • ACK indicates the receiver has successfully received the frame.
  • (Instructor analogy: WhatsApp-style confirmation “ticks”.)

Timeout mechanism

  • After sending a frame, the sender starts a timer.
  • If ACK is not received within the timeout period:
    • The sender assumes the frame wasn’t received
    • The sender retransmits the same frame

Important properties

  • Reliable, but inefficient for high-latency/high-bandwidth networks
  • Inefficiency cause: idle waiting time (only one frame “in flight” at a time)

Relation to sliding window

  • Stop-and-Wait is a special case of sliding window where:
    • Window size = 1

Issues discussed with Stop-and-Wait

  • Lost data (frame lost)
    • Frame is sent, but no ACK arrives
    • Sender retransmits after timeout
  • Lost acknowledgement (ACK lost)
    • Receiver got the data and sent ACK, but ACK is lost
    • Sender times out and retransmits unnecessarily (confusion risk)
  • Delayed acknowledgement
    • ACK arrives after timeout
    • Sender may treat it as belonging to a later transmission → duplicates/confusion

B) Sliding Window Flow Control

Core rule

  • Allows the sender to transmit multiple frames before waiting for ACK.

How it works

  • Sender and receiver maintain a window of frames.
  • As ACKs arrive, the window “slides” forward.

Performance benefits

  • Improves bandwidth utilization
  • Increases throughput
  • Enables continuous / pipelined transmission

Protocol Details Mentioned Inside Sliding Window

1) Stop-and-Wait ARQ (formal description)

  • Sender sends one frame at a time
  • Waits for ACK
  • If ACK not received within timeout → retransmit
  • Error control via:
    • acknowledgement + retransmission
  • Flow control:
    • allows only one outstanding frame
  • Uses two sequence numbers (0 and 1) to avoid duplication
    • Therefore it’s a special sliding window case (window size = 1)

2) Key timing/terms for numericals (formulas & definitions)

  • Propagation delay (PD)

    • Time for a data packet to travel physically from sender to receiver
    • Formula idea: distance between nodes / propagation speed of the signal

  • Round Trip Time (RTT)

    • Time for:
      • data frame to reach receiver +
      • ACK to return to sender
    • RTT = (data travel time) + (ACK travel time)

  • Timeout (Tout)

    • Maximum time sender waits for ACK before retransmitting
    • Timeout = Estimated RTT + Safety margin

Stop-and-wait sender/receiver behavior rule

  • Sender sends one data packet, then sends the next only after ACK
  • Receiver sends ACK immediately after successfully receiving each packet

3) Selective Repeat ARQ (within sliding window)

Core rule

  • Sliding window protocol where:
    • sender and receiver window sizes are equal

Retransmission behavior

  • Retransmits only the lost/corrupted frames
  • Uses independent timers per frame:
    • if a specific frame’s timer expires → retransmit that frame only

Buffering requirement

  • Requires buffering at both sender and receiver
  • Instructor note:
    • sender needs n buffers
    • receiver needs n buffers
    • total buffering = 2n

Sequence numbers

  • Sequence numbers must uniquely identify frames (required at both ends)

Window size restriction (MCQ-likely / very important)

  • Must avoid:
    • sequence number overlap
    • packet ambiguity
  • Must satisfy:
    • WS and WR ≤ (half of total sequence space)

Out-of-order delivery handling

  • If frames arrive out of order:
    • receiver buffers them
    • receiver sends individual ACK/NACK (NAC) based on each received frame situation

Efficiency / Performance Formulas for Selective Repeat (as described)

  • Instructor aims to compute efficiency for selective repeat.
  • Selective retransmission reduces unnecessary resends → better bandwidth utilization.

Efficiency definition (as stated)

  • Expressed as a ratio involving:
    • data transmission time
    • total time for successful transmission and ACK
  • Expanded form (as read):
    • Efficiency = (Data transmission time) / (Total time including multiple components)
  • Time components named:
    • TTdata: transmission delay of data packet
    • TP: propagation delay
    • TQ: queuing delay
    • Tprocess: processing delay
    • Tack: transmission delay of ACK packet

Relationship mentioned

  • Selective Repeat efficiency = Go-Back-N efficiency
  • Same efficiency expression is said to apply (per the class notes)

Multiple Access Protocols (Transition to Next Topic)

Multiple Access Protocol types (as listed)

  • Random access
  • Controlled access
  • Channelization protocols

Channelization methods (Low channel access methods)

  • FDMA (Frequency Division Multiple Access)

    • Divide available bandwidth into non-overlapping frequency bands
    • Assign a dedicated frequency to each user
    • Analogy: different radio/FM frequencies per user

  • TDMA (Time Division Multiple Access)

    • Use a single frequency band
    • Divide transmission time into repeating time slots
    • Assign different users different time slots

  • CDMA (Code Division Multiple Access)

    • All users share the same frequency band at the same time
    • Each user’s data is encoded with a unique orthogonal code
    • Receiver identifies which user corresponds to which code
    • Purpose: avoid collisions even with simultaneous transmission

Random Access Protocols (Aloha + CSMA)

Random access concept (priority)

  • All stations have equal priority
  • Transmission depends on channel condition (e.g., medium free/busy)
  • No fixed transmission order and no fixed time-slot assignment

ALOHA (wireless shared media)

  • Collision can occur when multiple stations transmit simultaneously
  • Two types:
    • Pure ALOHA
      • Devices can transmit at any time without coordination
      • Efficiency (as stated): maximum 18.4%
      • Variability period described as double the time to transmit one frame
    • Slotted ALOHA
      • Time is divided into discrete intervals (slots)
      • Transmissions align to slots (reduces collisions vs pure ALOHA)

CSMA (Carrier Sense Multiple Access)

Core principle

  • Listen before transmitting
    • If medium is idle → transmit
    • If medium is busy → wait

Subtypes mentioned

  • CSMA/CD (Collision Detection)
    • If collision occurs, detect it
    • Stop transmitting and wait for a random time (random backoff)
  • CSMA/CA (Collision Avoidance)
    • Uses methods to avoid collisions (random backoff + handshake signals described)
