CLASS-12 WAVE OPTICS

Young’s Double-Slit Experiment (YDSE)

The lecture covers YDSE concepts and numerical problems, focusing on interference conditions, fringe positions and spacing, intensity, the effect of a medium, and patterns produced by white light.

Main Concepts

• Interference requires coherent sources. Coherent waves maintain a fixed phase relationship, producing a stable pattern of bright and dark fringes. Independent, non-coherent sources do not produce a stable pattern; their average intensities add.
• Path difference determines the fringe type:
  • Bright fringes (constructive interference): (\Delta = m\lambda)
  • Dark fringes (destructive interference): (\Delta = (m+\tfrac{1}{2})\lambda)

Here, (m) is an integer and (\lambda) is the wavelength.

• YDSE geometry: For slit separation (d), screen distance (D), and a point at transverse position (y), the small-angle path difference is approximately [ \Delta \approx \frac{dy}{D}. ]

The fringe width—the distance between successive bright fringes or successive dark fringes—is [ \beta = \frac{\lambda D}{d}. ]

• Intensity of the interference pattern: For two coherent waves, [ I = I_1 + I_2 + 2\sqrt{I_1I_2}\cos\delta, ] where (\delta) is their phase difference. For equal-intensity waves, the central bright fringe is the maximum; complete cancellation can produce dark fringes.

• Effect of a medium: In a medium with refractive index (n), the wavelength becomes (\lambda_0/n), while the frequency remains unchanged. With the same slit and screen geometry, the fringe width is reduced by a factor of (n).

• Optical path: A material layer changes the optical path relative to the same distance in air. This can alter the path difference and shift the fringe pattern.

• White and monochromatic light:

  • With white light, the central fringe is white because all wavelengths have zero path difference there.
  • Away from the centre, different wavelengths reach maxima and minima at different positions, creating coloured fringes. Violet’s shorter wavelength places its fringes closer to the centre than red’s.
  • With monochromatic light, the fringes have that light’s colour, and their spacing depends on its wavelength.

Problem-Solving Approach

1. Identify the given quantities, such as (d), (D), (\lambda), path difference, or the medium’s refractive index.
2. Use the geometric path difference or the small-angle approximation (\Delta \approx dy/D), as appropriate.
3. For a bright or dark fringe, apply the corresponding path-difference condition.
4. To find fringe positions or spacing, use (y_m = m\beta) for bright fringes and (y = (m+\tfrac{1}{2})\beta) for dark fringes.
5. When counting fringes, distinguish between bright and dark fringes, and check whether the central bright fringe or endpoints are included.
6. Keep units consistent and use the wavelength in the medium when the experiment is immersed in a medium.
